globalaqua 2″ ro element
globalaqua™ household ro membrane elements for drinking water are one of the most reliable and consistent nsf certified products with high flow rate and excellent salwejection rate. a wide selection ranges from 24 gpd to 100 gpd, along with advanced membrane technology and precisely-controlled element rolling, we are confident that globalaqua™ high performance ro membranes are ideal for your residential or light commercial use.
- introduce
- introduce
- introduce
- related items
|
model |
dimension – inches (mm) |
||||
| a | b | c | d | e | |
| mtw-1812 | 11.75 (298) | 0.87 (22) | 0.68 (17) | 1.75 (44.5) | 10.00 (254) |
| mtw-2812-200g | 11.75 (298) | 0.87 (22) | 0.68 (17) | 2.60 (66.0) | 10.00 (254) |
| mtw-2812-300g | 11.75 (298) | 0.87 (22) | 0.68 (17) | 2.70 (68.5) | 10.00 (254) |
| mtw-3012-400g | 11.75 (298) | 0.87 (22) | 0.68 (17) | 2.89 (73.5) | 10.00 (254) |
| mtw-3012-500g | 11.75 (298) | 0.87 (22) | 0.68 (17) | 3.05 (77.5) | 10.00 (254) |
|
1812 residential reverse osmosis membrane
|
||||
|
model |
working pressure |
permeate flow | salt rejection | recovery rate |
|
mtw-1812-24g |
60psi |
24gpd |
96.0% |
15.0% |
|
mtw-1812-36g |
60psi |
36gpd |
96.0% |
15.0% |
|
mtw-1812-50g |
60psi |
50gpd |
96.0% |
15.0% |
|
mtw-1812-75g |
60psi |
75gpd |
96.0% |
15.0% |
|
mtw-1812-100g |
60psi |
100gpd |
96.0% |
15.0% |
|
2812 & 3012 commercial reverse osmosis membrane
|
||||
| model |
testing pressure |
permeate flow |
salt rejection |
recovery |
|
mtw-2812-200g |
100psi |
200gpd |
94.0% |
15.0% |
|
mtw-2812-300g |
100psi |
300gpd |
94.0% |
15.0% |
|
mtw-3012-400g |
100psi |
400gpd |
94.0% |
15.0% |
|
mtw-3012-500g |
100psi |
500gpd |
94.0% |
15.0% |
| membrane type | polyamide thin-film composite |
| maximum operating temperature | 113°f /45°c |
| maximum operating pressure | 300psi (21 bar) |
| ph range, continuous operation | 2-11 |
| ph range, short-term cleaning (30 min) | 1-12 |
| maximum feed silt density index (sdi) | 5 |
| free chlorine tolerance | < 0.1ppm |
